PCSC/CCID RFID Card Readers for Vending Machine
🚀 Advanced RFID Technology for Vending Machines
O PCSC/CCID Leitor de cartão RFID is designed for high-performance applications like vending machines. It supports ISO 14443 Part 4 Type A and B cards, FeliCa, and all NFC tags (ISO/IEC 18092). The reader communicates through a USB 2.0 full-speed interface, enabling fast read/write speeds of up to 424 Kbps. With built-in anti-collision features, it ensures that only one tag is accessed at a time, providing smooth, secure transactions.
This reader is CCID compliant and fully compatible with PC/SC applications, allowing easy integration into existing systems. It also features a user-controllable bi-color LED to signal status and operation.
Descrição
🔧 Seamless Integration and Versatile Performance
O RCR-2833 RFID card reader/writer connects seamlessly with your PC or vending machine system via USB. It serves as an intermediary device, handling communication between the computer and the contactless RFID tags. Whether you’re using it to access data from a card or control peripherals like LEDs or buzzers, the RCR-2833 responds quickly and efficiently to commands. It supports both PC/SC and CT-API, ensuring flexibility in various applications.
Ideal for businesses needing reliable and secure payment solutions, the RCR-2833 is perfect for integrating RFID technology into vending systems, access control, or any application requiring fast and reliable card reading.
Especificação:
| Unid | Parâmetro Técnico |
|---|---|
| Protocolo | USB CCID PCSC |
| Tipo de conector | USB tipo A padrão |
| Power Source Supply Voltage | From USB port 5 V |
| Velocidade | Read/Write speed of up to 424kbps |
| Padrão | Support for ISO 14443 part 4 Type A and B cards |
| Protocol Type | FeliCa and all four tyoes of NFC |
| Corrente de fornecimento | Máx. 50 mA. |
| Modo vinculado ao PC | PC/SC CT-API |
| Peso líquido | Aprox.: 0,3 Kg (sem acessórios) |
| Padrão ROHS | Cumprir com o padrão ROHS. |
| Temperatura | 0 °C – 60 °C |
| Umidade | Máx. 90% (sem condensação) |
• IEC/EN 60950 o ISO 18092
• ISO 14443
• CE
• FCC
• KC
• VCCI
• MIC
• PC/SC
• CCID
• Microsoft® WHQL o RoHS2
