Pcsc/Ccid Card Reader with Standard Type USB for Slot Machine
Our pcsc and ccid card reader follows the full PCSC and CCID protocols. It supports IC cards, CPU cards, financial cards, and identity cards. The reader ensures high compatibility across government, finance, enterprise, and healthcare systems. This design strengthens reliability for mission-critical authentication tasks.
Description
Government and Public Service Applications
The reader supports national ID verification and social security data access. It enables smooth medical insurance queries and housing fund services. Agencies use it to enhance digital governance workflows. Its secure architecture ensures fast and accurate identity processing.
Finance and Secure Payment Scenarios
Banks use the reader for USB keys and financial IC cards. It supports online banking transfers and POS identity checks. The design meets PCI DSS security requirements. Financial institutions benefit from stable encryption and dependable transaction verification.
Specification:
| Protocol | USB CCID |
|---|---|
| Connector Type | Standard Type A USB |
| Power Source Supply Voltage | From USB port 5 V |
| Speed | USB Full Speed (12 Mbps) |
| Standard | ISO 7816 Parts 1-3, Class A, B, C (5 V, 3 V, 1.8 V) |
| Supply Current | Max. 50 mA. |
| Smart Card Read/Write Speed | 9.6 Kbps – 480 Kbps |
| Short Circuit Protection | (+5) V/GND on all pins |
| Clock Frequency | 4 MHz |
| Card Insertion Cycles | Min. 100,000 |
| PC-linked Mode | PC/SC CT-API (through wrapper on top of PC/SC) |
| Online download | Support ISP online download. |
| Net Weight | Approx.: 0.3 Kg (without accessories) |
| ROHS standard | Comply with ROHS standard. |
| Temperature | 0 °C – 60 °C |
| Humidity | Max. 90% (non-condensing) |
Enterprise and Office Authentication
Employees log in to computers with secure card access. The reader supports encrypted file access and VPN authentication. It integrates with enterprise systems for unified identity management. Organizations use it to enhance internal security and workflow efficiency.
Medical and Education System Compatibility
Hospitals use the reader for medical insurance settlement. Schools use it for campus card verification and library card reading. The module ensures stable performance in high-traffic service points. It supports fast information access for staff and visitors.
Durable USB Type-A Interface Design
The PC/SC and ccid card reader uses gold-plated USB contacts. This design reduces oxidation risk and improves long-term stability. The interface supports 10,000+ insertions. A USB-C version is also available for modern device integration.
