Standard Type A USB Card Reader for Pcsc/Ccid
The Type A USB card reader follows PCSC and CCID standards. It works with IC cards, CPU cards, ID cards, and financial IC cards. It offers plug-and-play convenience across multiple systems. The device delivers stable and reliable performance for government, finance, enterprise, and healthcare applications.
Description
Applications in Government and Public Services
Government platforms use this reader for ID card expansion and identity verification. It supports social security and medical insurance inquiries. The reader assists in housing fund services and public information terminals. These capabilities enhance service efficiency in public offices.
Secure Use in Finance and Payment Systems
Financial institutions use the reader with bank USB keys and IC cards. It supports online banking transfers with strong stability. PCI DSS compliance ensures safe identity verification at payment terminals. The device helps banks and merchants maintain secure digital workflows.
Specification:
| Protocol | USB CCID |
|---|---|
| Connector Type | Standard Type A USB |
| Supply Voltage | 5 V |
| Speed | USB Full Speed (12 Mbps) |
| Standard | ISO 7816 Parts 1-3, Class A, B, C (5 V, 3 V, 1.8 V) |
| Protocol | T=0; T=1; Memory Card Support |
| Supply Current | Max. 50 mA. |
| Smart Card Read/Write Speed | 9.6 Kbps – 480 Kbps |
| Short Circuit Protection | (+5) V/GND on all pins |
| Clock Frequency | 4 MHz |
| Card Insertion Cycles | Min. 100,000 |
| PC-linked Mode | PC/SC |
| Online download | Support ISP online download. |
| Net Weight | Approx.: 0.3 Kg (without accessories) |
| ROHS standard | Comply with ROHS standard. |
| Temperature | 0 °C – 60 °C |
| Humidity | Max. 90% (non-condensing) |
Enterprise-Level Authentication and Access Control
Enterprises use the reader for employee card login and workstation security. It supports encrypted file access and VPN authentication. The reader strengthens system-level identity verification. It helps IT teams protect internal networks and sensitive data.
Support for Medical and Education Scenarios
Hospitals use the reader for medical insurance card settlement. Schools deploy it for campus card verification and library card reading. It ensures quick identity checks and smooth information access. The reader fits daily use in clinics, labs, and education centers.
Durable Type A USB Interface Design
The Type A USB interface uses gold-plated contacts to reduce oxidation. It supports over 10,000 insertion cycles. This durability ensures long-term stability in high-use environments. A USB-C version is available for modern device compatibility.
